Brand:Mondraker
Code:010.230
Is the most advanced carbon fibre development and optimisation technology in the Mondraker range. This constantly developing technology brings all the experience gained in making aluminium frames to top of the range carbon fibre to meet the same innovation, maximum quality, minimum weight and strength requirements. Carbon fibre layers’ placement is a crucial technique with specific positioning and direction of the different quality fibres for each bike type and model. The result is a frame with the best strength / structural rigidity / trail buzz absorption / lightness ratio, exceptional reliability and a very attractive and unique 100% Mondraker look.
ADVANTAGES
•Distinctive looks
•Leading carbon manufacturing process
•Best strength / structural rigidity / trail buzz absorption / lightness ratio
Frame
Chrono 29 Stealth full Carbon, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable routing, Boost 12x148mm rear axle, Comfort Flat chainstays (Flatstays) design
Sizes
S: 395mm / M: 430mm / L: 470mm / XL: 520mm
Fork
Fox 32 Step Cast Float FIT4 Evol Factory Kashima, 100mm, tapered steerer tube,15x110mm Boost axle, offset 44mm. Settings: remote 2pos Push-unlock, compression micro-adjustment at low-speed, rebound, air preload
Headset
ONOFF Titan tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41.8x30.5x8x45ºx45º, bottom 51.9x40x8x45ºx45º
Fork remote
Fox single pull
Stem
MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5º, length: size S: 60mm, size M: 70mm, size L: 80mm, size XL: 90mm
Handlebar
ONOFF Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 760mm, 9º backsweep, 0º upsweep, 31.8mm barbore
Grips
ONOFF Desert, 1lock-on, 135mm
Seatpost
ONOFF Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 27.2mm, length 400mm
Saddle
Mondraker XC Series, steel rail
Front brake
Sram Level T, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake
Brake lever
Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
Rims
Mavic Crossmax SL S 29, 25mm internal width, Maxtal welded rim, hookless, tubeless, 24 spokes
Spokes
Mavic straight-pull double butted, contactless lacing
Front hub
Mavic, Boost 15x110mm, IS 6 bolts
Rear hub
Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts
Front tire
Maxxis Ikon 29x2.20, 3CMaxx Speed compound, tubeless ready, 120TPI, folding bead
Rear tire
Crankset
Sram GX Eagle, Boost, DUB axle, Direct Mount chain ring, S size: 170mm, M/L/XL size: 175mm
Rings
34T, CNC-machined alloy, X-SYNC 2
Bottom bracket
Sram DUB BSA, sealed bearings, 73mm
Chain
Sram SX Eagle, 12s, Powerlock
Rear derrailleur
Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Shift levers
Sram Trigger NX Eagle, 12s, X-Actuation 1:1
Casette
Sram PG-1230, 11-50T, 12s
Derailleur hanger
Mondraker M068
Weight
10,2 kg
